There’s nothing worse than stepping onto a cold, hard tiled floor after a nice, hot shower or bath! The good news is there’s a way you can avoid this annoying inconvenience with electric under tile heating.

At Calibre Connect, we provide energy-efficient under tile heating in Sydney and the surrounding areas. This innovative and modern heating solution is ideal for many rooms, including bathrooms and showers, laundry rooms, kitchens, patios, and living rooms.

What’s more, our under-floor heating systems work with most floor coverings, including ceramic tiles, marble, slate, and stone, giving you a range of modern dΓ©cor options.

Why Choose Electric Under Tile Heating?

Electric under tile heating systems are the modern, cost-efficient way to heat your Sydney home. This heating solution warms up your surroundings while reducing disease-causing mildew, mould, and other microbes that often build up in wet areas.

Additional benefits of installing this innovative floor heating solution from Calibre Connect include:

  • Even heating: Underfloor heating retains heat efficiently and distributes heat from the floor upwards, ensuring all-around and even coverage.
  • Cleaner indoor environment: Lower dust circulation and mould occurrence make these heating systems perfect for people with allergies or chronic conditions like COPD and asthma.
  • Easy installation: Electric under-floor heating is straightforward to install. All it requires is cutting the heating floor mat to size, securing it in place, and then tiling over the whole system.
  • Higher energy efficiency: Under-floor heating eliminates cold drafts as they function under much lower temperatures and controlled thermostats, have fast warm-up times, and, unlike forced-air heating systems, generate heat from floor to ceiling, losing less heat in the process.
  • Zero maintenance costs: These heating systems are entirely out of sight, eliminating the need to wash or dust air filters and other moving system parts typically found in forced-air heating systems.
  • Suitable for modern decor: This heating solution is the ultimate clutter-free solution. It is entirely out of sight, ensuring that your home’s dΓ©cor remains flawless.

Interested in learning more about electric under tile heating for your Sydney home? Our team of under-floor heating experts will guide you through the installation process, leaving you with a low-maintenance and comfortable heating solution that will serve you for years. Call our Electricians at Calibre Connect today for high-quality underfloor heating in Sydney.

Innovative Heater Floor Mat Under Tile Heating System

Under-tile heating is a modern heating method that eliminates the need to use high-maintenance forced-air heating and cooling systems, ultimately cutting down on heating installation and maintenance costs.

This heating system is popular for existing homes or new builds with a finished and polished concrete slab installed. The process of installing the heater floor mat under tile is incredibly easy; qualified electricians from Calibre Connect will:

  • Cut and fix the floor sensor and heater mats, ensuring they are even across the heating area.
  • Temporarily fix the heating mat in position and then peel off the backing tape and stick it down.
  • Complete the heating system’s connection to the electrical mains
  • Tile over the whole heating area to secure the heating system

It’s no wonder Calibre Connect under-floor heating is popular in Sydney! Contact us now to discover how this heating system can give you superior comfort and warmth all year round.

Choose the Best Undertile Floor Heating Installation Company in Sydney

If you’ve considered getting electric under-tile heating in Sydney, consider hiring Calibre Connect. Our experienced electricians will get the job done right, leaving you with a beautiful, functional, and durable heating system that’s changed our ideas about modern, energy-efficient heating in the home. All of our personnel is licensed and insured and regularly undergo training to stay up-to-date with industry developments and regulations. We also believe in transparent and honest pricing, so our courteous electricians will provide you with a full written quote before any work commences. Finally, the under tile heating systems we use are Australian Electrical Standards AS3000-approved for your total peace of mind.Β

Get in touch today to learn more about electric under tile heating in Sydney, the modern and energy-efficient home heating solution! Call us atΒ (02) 8898 0200Β to schedule an appointment.

  • We had Calibre Connect do all of the electrical work associated with our kitchen renovation and we were incredibly pleased with the result! Marc was a pleasure to deal with throughout the whole process and he worked around our time schedule which was a big help. Honest, hard working, efficient and knowledgeable. We’ll definitely use Calibre Connect for future work. Thank you!
    elise giallonardo review
    Elise Giallonardo
  • Marc and his team always do a fantastic job. They are unafraid to give you straight answers and recommend options, allowing you to have complete confidence that they are thinking about all possible outcomes. Work is done efficiently and effectively, with an outstanding final product. I will not hesitate to use Calibre Connect again in the future!
    kurt sfiligoi electrical review
    Kurt Sfiligoi
  • Many thanks to Calibre Connect team for doing a series of electrical odd jobs around our apartment. The guys were super clean and very careful/considerate to our apartments furnishing. Very much a no stress and high quality experience. Thanks Marc!
    maxim consalvi electrical review
    Maxim Consalvi
Send Us Your Question and Get a Flash Response!

Under Tile Heating Installation – FAQs

Start by thoroughly cleaning and preparing the subfloor, ensuring it is level and free of debris. Lay down insulation and a damp-proof membrane if needed. Carefully position heating mats or cables without overlapping, securing them properly. Install the floor sensor correctly, test the system before tiling, and have a certified electrician connect the wiring. Finally, tile over with appropriate thinset and grout.

The floor sensor monitors the exact temperature of the tile surface to regulate the heating system accurately. Improper placement can cause inaccurate temperature readings, leading to overheating or insufficient heating. Correct sensor positioning ensures energy efficiency, safety, and comfort by maintaining the desired floor temperature.

Use a digital multimeter to measure the resistance of the heating mats. The resistance should match the manufacturer’s specifications within a 10% margin to confirm no damage. Test both before and after installation but before tiling to ensure continuity and functionality. This prevents costly repairs or tile removal later.

While some electric under tile heating kits are designed for DIY installation, it is recommended to hire a professional electrician for the electrical connections. This ensures compliance with safety standards, proper wiring, and reduces risks associated with electricity near wet areas like bathrooms.

You will need heating mats or cables, a thermostat with a floor sensor, thinset mortar, insulation boards or membranes, a digital multimeter, tape, scissors, and a permanent marker. Additionally, a crowbar or tools to remove existing flooring, and a professional electrician for final wiring are essential for safety and compliance.

After tiling, it’s best to leave the heating system off for at least 7 days to allow adhesives, grout, and screed to cure fully. Then, gradually increase the temperature by 3–5Β°C daily to allow the floor and heating elements to expand and settle without damage.

Tile has high thermal conductivity, meaning it quickly absorbs and transfers heat from the heating elements to the surface. Its high thermal mass allows it to retain heat longer, providing consistent warmth and reducing energy consumption. This makes tile an ideal flooring choice for radiant heating systems.

Electric under tile heating systems require minimal maintenance, mostly periodic checks of the thermostat and sensor. For wet systems, regular inspections for leaks, boiler pressure, and occasional bleeding of air from pipes are necessary. Annual professional servicing is recommended for optimal performance and longevity.
